若需要更詳細的規格請與我們聯繫

板對板連接器

0.50mm Pitch B To B SMT Type Height:2.0mm 連接器

0.50mm Pitch B To B SMT Type Height:2.0mm 連接器 (YA0510 Series)

規格 : Current Rating: 0.5A AC, DC Voltage Rating: 50V AC, DC Temperature Range: -25 deg C ~ +85 deg C Contact Resistance: 30m Omega Max. Insulation Resistance: 100M Omega Min.

0.60mm Pitch Housing SMT 連接器

0.60mm Pitch Housing SMT 連接器 (YA0600 Series)

規格 : Current Rating: 0.4A AC, DC Voltage Rating: 100V AC, DC Temperature Range: -25 deg C ~ +85 deg C Contact Resistance: 45m Omega Max. Insulation Resistance: 1,000M Omega Min.
0.80mm Pitch B To B SMT Type Height:3.0mm 連接器

0.80mm Pitch B To B SMT Type Height:3.0mm 連接器 (YA0802 Series)

規格 : Current Rating: 0.5A AC, DC Voltage Rating: 50V AC, DC Temperature Range: -25 deg C ~ +85 deg C Contact Resistance: 30m Omega Max. Insulation Resistance: 100M Omega Min.

1.25mm Pitch Terminal / Vertical Angle Housing 連接器

1.25mm Pitch Terminal / Vertical Angle Housing 連接器 (YA1259 Series )

規格 : Current Rating: 1A AC, DC Voltage Rating: 125V AC, DC Temperature Range: -25 deg C ~ +85 deg C Contact Resistance: 20m Omega Max. Insulation Resistance: 100M Omega Min.

1.50mm Pitch Terminal / Right Angle Housing 連接器

1.50mm Pitch Terminal / Right Angle Housing 連接器 (YA1502 Series)

規格 : Current Rating: 1A AC, DC Voltage Rating: 200V AC, DC Temperature Range: -25 deg C ~ +85 deg C Contact Resistance: 20m Omega Max. Insulation Resistance: 500M Omega Min.
2.00mm Pitch Terminal / Vertical . Right Angle Housing 連接器 2.00mm Pitch Terminal / Vertical . Right Angle Housing 連接器 (YA2011 Series)

規格 : Current Rating: 2A AC, DC Voltage Rating: 250V AC, DC Temperature Range: -25 deg C ~ +85 deg C Contact Resistance: 20m Omega Max. Insulation Resistance: 1,000M Omega Min.
2.00mm Pitch Terminal / Vertical Angle Dual Row Housing 連接器

2.00mm Pitch Terminal / Vertical Angle Dual Row Housing 連接器 (YA2012 Series)

規格 : Current Rating: 2A AC, DC Voltage Rating: 250V AC, DC Temperature Range: -25 deg C ~ +85 deg C Contact Resistance: 20m Omega Max. Insulation Resistance: 1,000M Omega Min.
2.50mm Pitch Terminal / Vertical . Right Angle Housing 連接器

2.50mm Pitch Terminal / Vertical . Right Angle Housing 連接器 (YA2512 Series)

規格 : Current Rating: 3A AC, DC Voltage Rating: 250V AC, DC Temperature Range: -25 deg C ~ +85 deg C Contact Resistance: 10m Omega Max. Insulation Resistance: 1,000M Omega Min.
2.50mm Pitch Terminal / Vertical . Right Angle Housing 連接器

2.50mm Pitch Terminal / Vertical . Right Angle Housing 連接器 (YA2513 Series)

規格 : Current Rating: 3A AC, DC Voltage Rating: 250V AC, DC Temperature Range: -25 deg C ~ +85 deg C Contact Resistance: 10m Omega Max. Insulation Resistance: 1,000M Omega Min.
3.96mm Pitch Terminal / Vertical Housing 連接器

3.96mm Pitch Terminal / Vertical Housing 連接器 (YA3965 Series)

規格 : Current Rating: 7A AC, DC Voltage Rating: 250V AC, DC Temperature Range: -25 deg C ~ +85 deg C Contact Resistance: 10m Omega Max. Insulation Resistance: 1,000M Omega Min.
